Product Details
＋
Features
- Large stroke, therefore suitable for using core drills, spiral drills and countersinks
- Magnetic base with high holding power permits working on vertical surfaces and overhead
- Metabo Long-life motor with patented dust protection for long service life
- Integrated coolant container for easy to dose internal cooling from the core drill
- Bright LED light for easy alignment in poor light conditions
- Chip protection guard can be fixed without tools and protects the user from metal shavings and tool contact
- Protective circuit starts motor only if the magnet is activated
- Restart protection: prevents unintentional start-up after power supply interruption
- Lockable slide for comfortable tool change
- Handle for easy carrying and lifting
- Sturdy electric cord (16') with rubber sheathing
What's in The Box
- 32 Magnetic Core Drill
- Ejector pin 75 mm
- Safety strap
- Allen wrench SW 4
- Chip Protection Guard
- Transport case
- Owner's Manual
Warranty
- 5 Year Limited Factory Warranty
- 30 Day Satisfaction Guaranteed
Specifications
| Sku | 600635620 |
| Brand | Metabo |
| Rated input power | 1000 W |
| Amps | 9 AMPS |
| Output power | 520 W |
| Max. drill-Ø with core drill | 1 1/4 " |
| Max. drill-Ø with spiral drill | 1/2 " |
| Maximum drilling depth | 2 " |
| No-load speed | 700 RPM |
| Revolutions at rated load | 450 RPM |
| Bit retainer | Weldon shaft 19 mm (3/4") |
| Weight | 26.2 lbs |
| Cable length | 16 ft |
| Torque | 443 in-lbs |
| Max. depth of feed | 6 5/16 " |
| Max. magnetic holding force | 12250 N |
| Dimensions of the magnet base | 3 9/16 x 7 1/2 " |
| Height of slide bottom setting | 13 1/2 " |
| Height of slide top setting | 19 9/32 " |
| Drilling in metal | 2.5 m/s² |
| Uncertainty of measurement K | 1.5 m/s² |
| Sound pressure level | 85 dB(A) |
| Sound power level (LwA) | 98 dB(A) |
| Uncertainty of measurement K | 3 dB(A) |
