Product Details
＋
Features
- High curve precision due to special cutting head geometry. Nibbler can turn on the spot
- Especially well-suited for cutting edged sheet metal with a minimum bend radius of 1/8 in
- Cutting direction setting can be changed in 45° increments up to 360° using tool-free rotating cutting head
- QuickIN rapid change system
- Optimal ergonomics
- Motor with outstanding performance and durability
- Ideal for cut-outs
- Optimally suited for template cuts
- Chip protection mesh on vent slots
- 16 ft. cable
- Stainless steel up to 19 gauge
What's in The Box
- Die (3 13 09 040 0 02)
- Punch (6 36 02 051 00 9)
- Owners Manual
Warranty
- 3 Year Limited Factory Warranty
- 30 Day Satisfaction Guaranteed
Specifications
| SKU | 72324060120 |
| Brand | Fein |
| Power consumption | 350 W |
| Power output | 210 W |
| Strokes | 500 - 1,000 spm |
| Cutting speed | 3.3 ft/min |
| Steel 58,000 lbf/in2 | 0.0787 in |
| Steel 87,000 lbf/in2 | 0.0591 in |
| Steel 116,000 lbf/in2 | 0.0394 in |
| Non-ferrous metals up to 36,000 lbf/in2 | 0.0984 in |
| Cutting width | 5/16 in |
| Immersion Ø with die | 11/16 in |
| Radius of smallest curve (inside/outside) | 1/4 in |
| Cable with plug | 16.4 ft |
| Weight | 3.97 lbs |
| Vibration and Sound Emission Values | |
| Sound pressure level LpA | 85 dB |
| Measurement uncertainty of the measured value KpA | 3 dB |
| Sound power level LWA | 91 dB |
| Measurement uncertainty of the measured value KWA | 3 dB |
| Peak sound value LpCpeak | 91 dB |
| Measurement uncertainty of the measured value KpCpeak | 3 dB |
| Vibration value 1 ahv 3-way | 7,3 m/s2 |
| Measurement uncertainty of the measured value Ka | 1,5 m/s2 |
